Tubing Cutter, Wheel Type. For stainless steel tubing. Black. ARE-Applied Research brand. 5/PK.
Additional Info:
The 46001‑01‑005 Wheel‑Type Tubing Cutter (5‑Pack) provides a bulk solution for laboratories working with stainless steel tubing, offering a reliable method for controlled scoring and clean breaking of metal tubing in non‑critical applications.
Cutting stainless steel tubing is one of the most challenging tasks in chromatography due to the risk of collapsing or narrowing the internal diameter, which can negatively affect flow and system performance. This cutter uses a wheel‑type scoring method, where the tubing is gradually scored around its circumference and then cleanly snapped. This approach helps preserve the internal bore and maintain flow integrity.
This tool is suitable for tubing with outer diameters ranging from 1/32" (0.8 mm) to 1/4" (6.4 mm) and features a precision cutting wheel (0.36 mm thickness) for consistent scoring performance.
While this cutter provides a good, usable cut for routine or non‑critical connections, it is not recommended for critical HPLC applications, where perfect perpendicular cuts and zero deformation are required. For high‑performance applications, ECM‑cut pre‑cut stainless steel tubing is strongly recommended.
After cutting, the tubing end should be cleaned and deburred using a file to ensure proper sealing and connection performance.
The 5‑pack configuration is ideal for multi‑user labs, service teams, and high‑throughput environments, ensuring tool availability across workstations.
Why Choose a 5‑Pack Tubing Cutter Set?
This configuration is ideal for:
Multi‑instrument chromatography labs
Service teams and maintenance groups
Reducing downtime from shared tools
Standardizing tubing preparation workflows
Why Use a Wheel‑Type Stainless Steel Cutter?
Improper cutting methods can lead to:
Collapse of the tubing inner diameter
Increased backpressure and flow restriction
Poor sealing and leaks
Reduced chromatographic performance
The scoring method used by this tool ensures:
Preserved internal diameter
Cleaner break vs full‑cut methods
Reduced deformation of tubing
More reliable non‑critical connections
Key Features
Designed for Stainless Steel Tubing
Handles OD range from 0.8 mm to 6.4 mm
Suitable for common chromatography tubing sizes
Controlled Scoring Method
Scores tubing instead of cutting completely through
Allows clean break with minimal internal distortion
Maintains flow path integrity
Precision Cutting Wheel
0.36 mm thickness for controlled scoring
Must be kept clean and sharp for best performance
Bulk Efficiency for Labs
5‑pack configuration for shared environments
Improves workflow efficiency and availability
Ideal for service and maintenance operations
Supports Non‑Critical Applications
Produces usable cuts for general lab use
Not intended for precision HPLC connections
Important Usage Notes
Recommended for:
Non‑critical stainless steel tubing cuts
Not recommended for:
High‑performance HPLC connections requiring precision cuts
For best results:
Use ECM‑cut pre‑cut tubing for critical applications
Deburr and clean tubing ends after cutting
Maintain cutting wheel condition
Typical Applications
Cutting stainless steel tubing for general lab use
Routine system maintenance and repairs
Non‑critical chromatography connections
Service and installation work
Multi‑user or high‑volume lab environments
